Industrial Automation using PLC and HMI

Request More Info

What you will learn

  • Locating CompactLogix Systems Components
  • Edit, modify, develop, and troubleshoot PLC ladder Logic programming for automated processes.
  • Navigating through the Logix Designer Application
  • Troubleshooting Controller Problems
  • Practice the skills you have learned through a variety of hands-on exercises.

Course Description

Upon completion of this course, you should be able to troubleshoot a previously operational CompactLogix system and restore normal operation.

In this course you will develop and practice these skills by:

  • Learning basic concepts and terminology used with:
      + CompactLogix system hardware
      + Studio 5000 Logix Designer® application
  • Practicing a systematic strategy for diagnosing and troubleshooting problems:
      + Faulty/malfunctioning field devices
      + Controller, I/O, or other hardware issues
      + Electrical Noise
      + Configuration issues
  • Performing hands-on exercises

Who should take this course?

  • Mechatronics Engineers
  • Electrical/ Electronics Engineers
  • Manufacturing Technicians
  • Process Control Technician
  • Operators
  • Contractors working with HMI development
  • Engineering Students
